Hidden Winch Plate, MAER, Isuzu D-Max 2020 - Present

• Bolted to factory mounting points
• Designed specifically for the Isuzu D-Max
• Made from 6 mm to 16 mm thick S355 J2+N carbon steel
• CNC laser-cut components for a precise fit
• CNC press-formed for structural strength
• Suitable for winches with a maximum pulling force of 12,500 lbs / 5,670 kg

Dimensions:

• Length: 893 mm
• Width: 342 mm
• Weight: 18 kg

Notes:

• The winch plate may interfere with the factory engine cover plate - may need to be trim or removal
• We recommend purchasing a compatible MAID-209-06-0000-00 cover plate (sold separately)
